<title>WR Series Automatic Powertrain Laser Welding Production Line

Double-head Asynchronous Automatic Feeding CO2Laser Cutter Series

CMA1612C-DFVET-A

Laser power(w):80-130W

Original advanced imported laser generator, with high quality light dot and stable output, enabling the high-precision cutting; The Gantry, made of lightweight carbon ﬁber material (Al), initial application to laser industry, with extremely stable performance; Various embedded sensors to monitor and collect data in real time; the powerful OEE system can meet the requirements of Industrial 3.0 to intelligent equipment; The whole transmission system adopts fully automatic CNC lubrication system, supporting 24-hour continuous cutting;.

Features

Integrated multi-functions into one, create more value for customer

Double crossbeams asynchronous cutting system can be installed with single crossbeam with single head or single crossbeam with twin heads. So the laser cutting machine has the double crossbeams with two heads or four heads
The double crossbeams work independently to process the different patterns, more efficient；
The motion system adopts multiple sets of step motors with high inertia and torque to ensure high-speed and high-precision operation；Rigid square tube welding body with sheet metal housing to ensure smooth operation；
The rail motion system is independently developed by YUEMING, light weight, high rigidity and good dynamic performance；

Parameters

Optimization and innovation, make product faster, more stable and more assured.

Model	CMA1612C-DFVET-A/CMA1814C-DFVET-B
Working area	1600×1000mm/1750×1150mm
Overall dimension	2330×2190×1900mm/2205×2500×1950mm
Laser power	80~130W
Speed	0~20m/min
Weight	900kg/950kg
Supply voltage	220-240V 50/60Hz
Working environment	Temp:5~40°C Humidity:5~80% Clean

→ Machine information and data

*The appearance, parameters, performance description, data, etc. of the products displayed on this page are all from the testing and experimentation of our company's own products in the internal laboratory of Dan's Yueming Laser Factory. They are for reference only, and the actual product shall prevail.

Application

Cutting of flexible composite materials for automobile safety airbags .

Product Video

Every detail strives for perfection, with humanized operation desks, all-round design, and stainless steel edging, to create industrial products with luxury requirements to meet your needs for product appearance and taste.
